Yale GA Pressure Gauge Adaptors ? Hydraulic Connections for Pressure Monitoring

YAL-HYG-GA

Pressure gauge adaptors with sleeve nut and 30ø inclination for clear, easy reading on Yale HPS hand pumps.

£63.66£76.39 Exc VATInc VAT

If you would like to request a change to this product that isn’t available within the current options, please enter your requirements here. Any modifications will need to be processed through our quote system rather than purchased directly online.

Add to Quote

Description

Yale GA Pressure Gauge Adaptors are designed for the safe and convenient connection of pressure gauges to Yale HPS series hand pumps. The integrated sleeve nut and 30ø angled gauge orientation provide excellent readability while reducing mechanical stress on the gauge and connection points.

These adaptors ensure a secure, leak-free connection and allow the pressure gauge to be positioned in a clearly visible orientation, even in confined working areas. Manufactured for use in high-pressure hydraulic systems, GA adaptors are fully compatible with Yale hand pumps and accessories.

Technical data
Model Art.-No. Gauge connection Oil port (pump side) Oil port (hose side)
GA-700 N14200201 G 1/4 3/8 NPT outer 3/8 NPT inner
GA-701 N14200208 G 1/2 3/8 NPT inner 3/8 NPT inner

Typical applications
Connection of pressure gauges to HPS hand pumps
Monitoring hydraulic operating pressure
Mobile and stationary high-pressure hydraulic systems

Technical information

Weight N/A
Connection

G1/4, G1/2

Key Features

Pressure gauge adaptor with integrated sleeve nut 30ø inclined gauge position for improved readability Suitable for all Yale HPS hand pumps Secure and reliable high-pressure connection Compact, robust design for workshop and site use
