Donati DRH Fixed Electric Wire Rope Hoist – Up to 50,000 kg
DON-EWRHDRH-FIXED
The Donati DRH Fixed Electric Wire Rope Hoist is a high-performance industrial lifting solution designed for static installations up to 50,000 kg working load limit. Built for durability and precision, this fixed mount hoist is ideal for gantry systems, production lines, and permanent lifting stations requiring reliable, heavy-duty lifting without beam travel.
Price on request
Description
The Donati DRH Fixed Electric Wire Rope Hoist is a robust and reliable industrial lifting solution engineered for heavy-duty applications where horizontal movement is not required. As the base configuration within the DRH range, this fixed mount hoist is designed for secure installation onto support structures, gantry systems, and stationary beams, providing powerful and consistent lifting performance.
Why Choose a Static Hoist?
With a working load limit of up to 50,000 kg, the DRH fixed hoist is ideally suited for manufacturing facilities, engineering workshops, production lines, and industrial processing environments. Its static configuration makes it particularly effective for dedicated lifting stations, where precision, strength, and reliability are critical.
Unlike trolley-mounted hoists, the fixed version is supplied without a travel mechanism, instead featuring heavy-duty fixing eyebolts for secure attachment to structural frameworks. This design ensures maximum stability during operation and reduces mechanical complexity, resulting in lower maintenance requirements and increased long-term reliability.
High Manufacturing Standards
Manufactured in Italy to the highest engineering standards, the DRH hoist is widely recognised for its precision construction, durability, and safety performance. Each unit is built using high-tensile steel components and advanced machining processes, ensuring consistent lifting performance even under continuous industrial use.
At the heart of the system is a self-braking electric hoist motor, which provides controlled lifting and safe load handling. The braking system automatically engages in the event of power loss, ensuring maximum safety during operation. This is complemented by precision-machined gear systems and enclosed lubrication, delivering smooth, quiet lifting cycles and reduced wear over time.
Configure Your Donati Hoist
The DRH fixed hoist is available across a range of models (DRH 1–4), covering lifting capacities from 800 kg to 50,000 kg, with duty classifications from FEM/ISO 1Bm (M3) to 3m (M6). This allows the hoist to be tailored to both light-duty and intensive industrial applications.
A wide range of lifting speeds is available, including both single-speed and dual-speed configurations. Dual-speed operation provides enhanced control, allowing operators to perform both rapid lifting and precise positioning when required.
The hoist also offers flexible hook run options, with multiple drum configurations (C, N, L, X1, X2) enabling lifting heights of up to 58 metres. This makes it suitable for installations with varying vertical lifting requirements, from compact workstations to large industrial facilities.
Donati Hoist Have Reliability and Safety Built-in
Electrical safety and reliability are ensured through IP-rated protection systems, thermal motor sensors, and integrated overload protection, ensuring safe operation in demanding industrial environments. The hoist is designed to operate in temperatures ranging from –10°C to +40°C, making it suitable for most indoor industrial applications.
All components are protected with a water-repellent electrostatic paint finish, providing excellent resistance to corrosion, humidity, and wear. This ensures long-term durability and consistent performance, even in harsh working conditions.
Typical Applications
Fixed lifting stations in production lines
Industrial gantry crane systems
Manufacturing and fabrication plants
Heavy machinery handling and installation
Warehousing and material handling
Maintenance and repair operations
Technical information
| WLL | 1.25t, 1.6t, 10t, 12.5t, 16t, 1t, 2.5t, 20t, 25t, 2t, 3.2t, 32t, 40t, 4t, 50t, 5t, 6.3t, 8t, 800kg |
|---|---|
| Lifting Speed (m/min) | 12.12/4, 2.2/0.7, 2.7.2.7/0.9, 3, 4.4/1.3, 6.6/2, 8.8/2.6, 4 |
| Duty Class | Heavy duty | 2m | M5, Intensive Duty | 3m | M6, Light duty | 1Bm | M3, Medium duty | 1Am | M4 |
Key Features
- Maximum Working Load Limit: Up to 50,000 kg
- Fixed mount design for static lifting applications
- Heavy-duty electric wire rope hoist system
- Self-braking motor for enhanced operational safety
- Wide range of lifting speeds (single and dual speed)
- Multiple drum configurations for hook runs up to 58 m
- Precision-machined steel components for durability
- IP-rated electrical protection and thermal sensors
- Low-noise operation (<80 dB)
- Minimal maintenance requirements
Safety & User Instructions
- Never exceed the maximum working load limit (WLL).
- Ensure installation is completed by qualified lifting equipment professionals.
- Verify that the supporting structure is rated for the hoist capacity.
- Operators must be trained in safe lifting procedures and equipment use.
- Perform regular inspection and maintenance of wire rope, motor, and safety systems.
- Keep lifting zones clear of personnel and obstructions during operation.
