Camlok® TTR Girder Grab for Vertical Transport – 750kg to 3t WLL
CAM-GC-TTR
The Camlok TTR Girder Grab enables safe lifting, transporting, and horizontal stacking of RSJ girders via their vertical flange. Designed for steel stockholders and fabrication shops, with capacities from 50–3000 kg.
From: £471.16£565.39 Exc VATInc VAT
Description
The Camlok® TTR Girder Grab is a specialised clamp designed to lift, transport, and horizontally stack steel girders by gripping the vertical flange. This makes it ideal for use in steel stockholding yards, fabrication workshops, and environments where girders need to be safely positioned and stored flat.
Once positioned on the girder’s vertical flange, the clamp is secured using the jaw locking lever, ensuring a reliable and stable grip before lifting begins. The TTR clamp can be used individually for shorter girders, while longer beams should be lifted using a pair of clamps and a spreader beam to maintain stability and prevent rotation.
With a capacity range from 50–3000 kg, the TTR girder grab offers robust performance and safe handling across a wide range of beam sizes. The hook ring must always face the centre of the beam when lifting to ensure safe load balance.
Technical information
| Weight | N/A |
|---|---|
| WLL | 1.5t, 3t, 750kg |
| Jaw Capacity (mm) | 5-16, 5-25, 5-28 |
